RF Jumper Cables Meet Relative or Absolute Phase-Matching Needs

Feb. 19, 2025

Materials, match testing, and final assembly processes ensure precision and a consistent phase relationship between cables within sets.

David Maliniak

Related To: Microwaves & RF

The Overview: Phase Matching Engineered In-House

Thanks to a meticulous phase-matching process, CDM Inc. offers RF jumper-cable assemblies that meet users’ demands for length, dielectric materials, and temperature specifications. With this capability, CDM offers a single resource for cable design, materials requirements, testing, and final assembly.

Who Needs It & Why: Precision Signal Arrivals

Many timing-critical applications require sets of cables ensuring that signals arrive at a specific point in the wave cycle. These include, but are not limited to, phased-array antennas, high-speed digital interconnects, military and aerospace radar, healthcare equipment, test and measurement equipment, and satellite communications.

Under the Hood: Rigorous Test and Assembly Processes

Two types of phase matching are offered in CDM’s RF jumper-cable assemblies. One is absolute phase matching; each cable in the assembly is matched to a specific phase value. The other is relative phase matching, in which cables in a set are matched to each other but not necessarily set to a specified absolute phase value.

CDM identifies and sources the specified cable lengths, dielectric materials, and temperature parameters, which are the primary factors affecting phase matching. The company uses Rohde & Schwarz test equipment, including a ZNL20 vector analyzer that provides a frequency range of 5 kHz to 20 GHz, and a ZNLE vector analyzer that covers 100 kHz to 20 GHz. All assembly work and phase-match testing take place at CDM’s Turnersville, N.J., manufacturing facility.
