High-Frequency Test Solutions for 5G, Military and Aerospace Applications on Display at EDI CON

​Anritsu Company will display test solutions and technologies that perform highly accurate measurements on high-frequency designs under development for 5G systems, as well as for military and aerospace applications in its booth (#121) at EDI CON USA. Advanced systems integrating vector network analyzers (VNAs) that extend to 110 GHz, as well as signal analyzers that provide engineers with the frequency coverage and measurement capability necessary to confidently validate their high-frequency designs will be shown.

Anritsu will also unveil the Power Master MA24507A, an ultraportable USB power analyzer that enables simple, numeric, frequency based measurement of RF power from 9 kHz to 70 GHz that provides cost and performance advantages in many millimeter wave (mmWave) applications at the show. The world’s first frequency selectable RF power analyzer, the Power Master MA24507A leverages Anritsu’s patented Shockline technology to address the growing number of test requirements in mmWave applications.

Many 5G designs will use E-band and millimeter wave (mmWave) frequencies, and Anritsu will demonstrate test solutions for these applications. The Signal Analyzer MS2840A with the High Performance Waveguide Mixer MA2808A, along with the Signal Generator MG3697C, which can test wireless backhaul and automotive radar, will be shown. To test 5G components operating in the E-band, Anritsu will showcase the ShockLine 2-Port Performance VNA with 60-90 GHz frequency coverage. The Power Master MA24507A is also well suited for E-band designs.
