Adapter Protects X-Band Components

Oct. 18, 2013
A waveguide-to-coaxial adapter provides overload protection for components from 8.2 to 12.4 GHz.
Download this article in .PDF format
This file type includes high resolution graphics and schematics when applicable.

The model 2A8BAW X-band Iso-Adapter is designed for applications from 8.2 to 12.4 GHz requiring a transition from waveguide to coaxial lines. Over that frequency range, the unit offers 18-dB isolation between ports with insertion loss of only 0.5 dB. Ideal for protecting sensitive components from input signal overloads, the adapter handles 5 W CW power and 1 W reflected power. It exhibits a typical VSWR of 1.30:1 for operating temperatures from 0 to +65°C. It measures 1.92 x 1.63 x 2.75 in. The unit includes a Type-N female connector at one port and WR90 waveguide interface with UG135/U flange at the other port.

Renaissance Electronics & Communications, LLC, 12 Lancaster County Rd., Harvard, MA 01451; (978) 772-7774.
