    Resistors Redo
    1. Technologies
    2. Components

    Resistor Two Day is Today

    Feb. 22, 2022
    Today is 2-22-22. Resist the urge to encode it.
    William G. Wong
    Related To: Electronic Design

    This article appeared in Electronic Design and has been published here with permission.

    Color coding is a common way to provide easy identification of characteristics like the resistance value of a resistor. Electronic Design is celebrating its 70th anniversary this year, but the encoding scheme employed with resistors predates this starting back in the 1920s. The Radio Manufacturers Association (RMA) came up with its standard (Fig. 1).

    1. The resistor coding started in the 1920s by the Radio Manufacturers Association. (Credit: Creative Commons 3)
    1. The resistor coding started in the 1920s by the Radio Manufacturers Association. (Credit: Creative Commons 3)

    Today is the 2nd of February in the year 2022, and red is the color used to encode two. Unfortunately, today’s five-band scheme uses a different color for the five band that indicates the tolerance of the resistor. Of course, we can cheat and apply red instead of silver or gold to get a red five-band resistor. This would have a rating of 22,200 Ω. If the last red band was a golden red, then the tolerance is ±5% (Fig. 2).

    2. The commonly used resistor color code uses five color rings. (Credit: Creative Commons 1)
    2. The commonly used resistor color code uses five color rings. (Credit: Creative Commons 1)

    The numeric encoding for the first three or four bands is:

    • 0 – black
    • 1 – brown
    • 2 – red
    • 3 – orange
    • 4 – yellow
    • 5 – green
    • 6 – blue
    • 7 – violet
    • 8 – grey
    • 9  – white

    Innumerable mnemonics have been used to help recall this sequence. Some can’t be repeated, but here are a few I found on Wikipedia:

    • Bad Beer Rots Out Your Guts But Vodka Goes Well – Get Some Now
    • Betty Brown Runs Over Your Garden But Violet Gingerly Walks
    • Bad Bears Raid Our Yummy Grub But Veto Grey Waffles

    Capacitors also can use this color-coded approach. There may be additional bands to specify a voltage rating class as well as temperature characteristics.

    These days, tiny surface-mount devices cover most of a printed circuit board. Colorful devices and even through-hole, wire resistors and capacitors are still utilized. Printing is a bit better on tiny devices and text is often used these days instead of color coding, but color still crops up even now.

    Nevertheless, it’s a red day for resistors and capacitors. Enjoy.
