A band-pass filter with ring resonator topology synthesized with Filter Designer 2D.

Design Tool Streamlines Planar-Filter Development Workflow

Oct. 3, 2014
The addition of Filter Designer 2D to CST’s Studio Suite enables the creation of fully parametric filter models for circuit simulation or full-wave 3D simulation.

Computer Simulation Technology (CST) added Filter Designer 2D to CST Studio Suite, allowing for the synthesis, electromagnetic simulation, optimization, and multiphysics analysis of filters with a single tool. Filter Designer 2D includes a database of a wide variety of filter types, including both lumped element and distributed element implementations. Users can input the filter’s specifications—including frequency response and physical limitations—and the software will automatically suggest a design. Fully parametric models of the design can be created for either circuit simulation or full-wave 3D simulation. CST’s system assembly and modeling (SAM) design-automation framework facilitates model simulation and optimization when fine-tuning performance, taking into account unforeseen coupling between elements. SAM can also be used to integrate the filter models into larger systems.

Computer Simulation Technology, 492 Old Connecticut Path, Suite 500, Framingham, MA 01701; (508) 665 4400
