Megahertz-Range Wireless-Power-Transfer Rectifiers Resonant To Regulate

Jan. 10, 2014
The goal of efficient and compact wireless energy transfer is driving innovations with resonant circuits so that more applications can ditch the wire.
Download this article in .PDF format
This file type includes high resolution graphics and schematics when applicable.

As more products are designed with wireless charging capability, resonant wireless-power-transfer (WPT) technology is increasingly present in the wireless market. Having faster and more reliable charge rates—while using less expensive or space-consuming electronics—is a major goal for this industry. At the Korea Advanced Institute of Science and Technology, Jun-Han Choi, Sung-Ku Yeo, Seho Park, Jeong-Seok Lee, and Gyu-Hyeong Cho designed and tested several resonant regulating rectifiers for enhanced WPT capability at 6.78 MHz.

On 0.35-micrometer bipolar-CMOS-DMOS (BCD) technology, the team is able to design RWPT circuits that can harvest power to 6 W at 86% efficiency using both the continuous conduction mode (CCM) and discontinuous conduction mode (DCM). The proposed resonant-regulating-rectifier designs do not require an additional inductor for switch-mode regulation, as the resonant tanks are operated using phaser-transformed inductance. Only three switches are used in a rectifier design that achieves 6 W of transferable power. Such a feat is impressive when compared to other resonant-regulating-rectifier systems that have been reported, which have less than 1 W of available power at 13.56 MHz. See “Resonant Regulating Rectifiers (3R) Operating for 6.78 MHz Resonant Wireless Power Transfer (RWPT),” IEEE Journal of Solid-State Circuits, Dec. 2013, p. 2989.

Download this article in .PDF format
This file type includes high resolution graphics and schematics when applicable.
